Construction drawing Bay window

Construction drawing erker

Realising a erker starts with a good construction drawing. It tells the municipality what you are going to build, tells your contractor what to make and prevents surprises during the renovation.

I want a erker, where do I start?

Start with your wishes: the dimensions, the layout and the desired materials. Then gather what already exists, photos of the current situation and any old drawings. With that information our building engineers professionally work out both the existing and the new situation, ready for the next step.

Do I need a permit for a erker?

That depends on the location and dimensions: at the rear you can often build permit-free, at the front or side usually not. Our drawings meet the submission requirements of municipalities throughout the Netherlands, so when an environmental permit is needed you can submit directly via the Omgevingsloket.

What is on the drawing?

You receive floor plans, elevations and sections to scale, of both the existing and the new situation, in accordance with the Dutch building regulations (Bbl). You get everything as a PDF to share and as an editable DWG file for your contractor. A structural calculation with structural drawing is easy to order alongside.

What does a construction drawing for a erker cost?

You put the drawing together directly online above at a fixed price. Choose your delivery time, add any options and you immediately see what it costs. One free revision round is always included.
